ZW-T040HCSA-03

4 inch 480*480 Square Shape LCD Module with IPS Technology

ZW-T040HCSA-03 is a TFT-LCD module. It is composed of a TFT-LCD panel,driver IC,FPC,a back light unit.The 4.0” display area contains 480X(RGB)X480 pixels and can display up to 262K colors.This product accords with RoHS environmental criterion.

ZW-T040HCSA-03 outline drawing

Feature Specification Unit
Brand Disea -
Size 3.95 inch
Resolution 480*480 dots
Pixel pitch 0.219(H)*0.219(V) mm
Display Mode IPS/NB -
Viewing Direction ALL o'clock
Gray Scale Inversion Direction ALL o'clock
Luminance 400 cd/m2
LCM (W * H * D) 74.83*78.98*2.02 mm
Active Area (W * H ) 71.86*70.18 mm
With /Without TP Without TP -
LED Numbers 4S2P-LED pcs
Operation temperature -20~+70
Storage temperature -30~+80
Interface 18BIT RGB -
LCM Power Supply 2.8 V
LED  Power Supply 12.0  V
Color Depth 262K -
LCM Driver IC ST7701S -
CTP Dricer IC - -

Stock and Customization

Please contact us for product availability. In most cases customers need to customise their own TFT LCD screen. Our experienced project managers can help you evaluate your project, recommend the most suitable product or make the most logical customisation suggestions. The evaluation is free of charge and we're happy to help even if you don't decide to go with us.
