7 inch 800×480 LCD Panel with IPS Technology

ZW-T070JWHA-02P is a TFT-LCD module. It is composed of a TFT-LCD panel, driver IC, FPC, a back light and RTP unit. The 7.0 display area contains 800xRGBx480 pixels and can display up to 16.7M colors. This product accords with RoHS environmental criterion.

ZW-T070JWHA-02P outline drawing

Feature Specification Unit
Brand Disea -
Size 7.0  inch
Resolution 800x480 dots
Pixel pitch 0.193(H)×0.1905(V) mm
Display Mode IPS/NB -
Viewing Direction ALL o'clock
Gray Scale Inversion Direction ALL o'clock
Luminance 400 cd/m2
LCM (W * H * D) 165.00*104.60*6.30 mm
Active Area (W * H ) 154.40*91.44 mm
With /Without TP Without TP -
LED Numbers 3S8P-LED pcs
Operation temperature -20~+70
Storage temperature -30~+80
Interface RGB666 -
LCM Power Supply 3.3 V
LED  Power Supply 9.0  V
Color Depth 16.7M -
LCM Driver IC HX5281-B -
CTP Dricer IC - -
