ZW-T177SSI-05

1.77 inch 128*160 TFT LCD Module With ILI9163V IC

ZW-T177SSI-05 is a TFT-LCD module.It is composed of a TFT-LCD panel,driver IC,FPC,a back light. The 1.77 display area contains 128X(RGB)X160 pixels and can display up to 16.7M colors.This product accords with RoHS environmental criterion.

Feature Specification Unit
Brand Disea -
Size 1.77 inch
Resolution 128*160 dots
Pixel pitch 0.219(H)*0.219(V) mm
Display Mode TN/NW -
Viewing Direction 6 o'clock
Gray Scale Inversion Direction 12 o'clock
Luminance 220 cd/m2
LCM (W * H * D) 34.70*46.70*2.60 mm
Active Area (W * H ) 28.03*35.04 mm
With /Without TP Without TP -
LED Numbers 2-LED pcs
Operation temperature -20~+70
Storage temperature -30~+80
Interface MCU-8bit/20PIN -
LCM Power Supply 2.8 V
LED  Power Supply 3 V
Color Depth 262K -
LCM Driver IC ILI9163V -
CTP Dricer IC - -

1.77 inch TFT LCD outline drawing

Stock and Customization

Please contact us for product availability. In most cases customers need to customise their own TFT LCD screen. Our experienced project managers can help you evaluate your project, recommend the most suitable product or make the most logical customisation suggestions. The evaluation is free of charge and we're happy to help even if you don't decide to go with us.
