2.0 inch 480*480 Round TFT LCD Module

Production State
In Production
Stock Quantity
10 PCS

ZW-T021BCSA-01 is a TFT-LCD module.It is composed of a TFT-LCD panel,driver IC,FPC,a back light unit.The 2.1 display area contains 480X(RGB)X480 pixels and can display up to 16.7M colors.This product accords with RoHS environmental criterion.

ZW-T021BCSA-01 outline drawing

Feature Specification
Brand Disea
Size 2.1 inch
Resolution 480*480
Pixel pitch 0.111(H)*0.111(V) mm
Display Mode IPS
Viewing Direction ALL
Gray Scale Inversion Direction ALL
Luminance 250
LCM (W * H * D) 56.18*59.71*2.20 mm
Active Area (W * H ) 53.28*53.28 mm
With /Without TP Without TP
LED Numbers 4P-LED pcs
Operation temperature -20~+70℃
Storage temperature -30~+80 ℃
Interface 18BIT RGB
LCM Power Supply 2.8V
LED  Power Supply 3.0 V
Color Depth 262K
LCM Driver IC ST7701S

Stock and Customization

Please contact us for product availability. In most cases customers need to customise their own TFT LCD screen. Our experienced project managers can help you evaluate your project, recommend the most suitable product or make the most logical customisation suggestions. The evaluation is free of charge and we're happy to help even if you don't decide to go with us.
